Project Overview

PET film + aluminum composite. Racing industry PCB panels with ±0.1mm lamination precision.

⚠️

The Challenge

Automotive designer wanted metal-like appearance with plastic weight and cost benefits. The racing industry PCB panels required:

•Lightweight alternative to solid aluminum •Superior thermal management •Precision-machined mounting points •High-quality surface finish •EMI shielding properties

✨

Our Solution

We developed a proprietary composite solution:

1. Material Innovation - Layered construction: PET film + aluminum core + PET protective layer - 60% weight reduction vs solid aluminum - Excellent thermal conductivity - Built-in EMI shielding

2. Process Excellence - Precision lamination at ±0.1mm - CNC machining for mounting holes - Surface finishing options: brushed, matte, glossy

3. Testing - Thermal cycle testing (1000 cycles) - Vibration testing (50G) - Salt spray testing (500 hours)

Related Technical Guides

Custom Acrylic Display Cases Design Guide

Design guide for retail display cases.

Luxury Retail Fixtures

Why premium brands choose acrylic.

Technical Specifications

Material	1.9mm Aluminum + PET Film
Precision	±0.1mm lamination
Surface	Brushed/Matte/Glossy
Temperature Range	-40°C to +120°C
Application	Racing PCB Panels
Output	1,500/month

Project Timeline

Total: 1,500/Month

🎨

Day 1

Design & Mockup

Pattern design

→

🔧

Day 2-3

Metal Fabrication

Frame fabrication

→

✨

Day 4

Overlay Process

Metal-acrylic bonding

→

✓

Day 5

Final QC

Adhesion test

→

🚚

Day 6

Packaging

Shipping preparation

Project Gallery

Client Testimonial

"The weight reduction transformed our product design possibilities. Our racing PCB panels are now 60% lighter while maintaining structural integrity. PlasioTech's composite expertise is unmatched in the industry."

Design Lead

Automotive Company
